    50 / 60HZ FG WILSON Generator Set , 100KW 125KVA Super Silent Diesel Generator Set

    Ask Lasest Price
    Brand Name : STONE POWER
    Model Number : SY125E5
    Certification : CE
    Price : Negotiable
    Delivery Time : one month
    • Product Details
    • Company Profile

    50 / 60HZ FG WILSON Generator Set , 100KW 125KVA Super Silent Diesel Generator Set

    50 / 60HZ FG WILSON Generator Set , 100KW 125KVA Super Silent Diesel Generator Set


    Generator setModel No.SY125E5
    Standby power104KVA/110KW
    Rated power125kVA/100KW
    Output voltage230/400
    Rated speed (r/min.)1500
    Noise level(7m)72dB
    Power factorCOSΦ=0.8(lagging)
    Phase/wires3 phase 4 wires
    Start modeElectric
    Fuel consumption20 L/h
    Rated currency(amps)180
    ProtectionLow oil-pressure, High water temperature, Over-speed, Over-current.
    EngineBrandYTO (FG WILLSION OEM)
    ModelLR6A3L-D
    Original:China
    Cylinders6
    Fuel0# light diesel
    Inter-CoolingNo
    Comprssion Ratio17:1
    Engine Power (prime/standby)120KW/132KW
    AspirationTurbocharged
    Governor/ClassMechanical
    Bore and stroke105×125 mm
    Start modeDC24V electric start
    Cylinders LayoutIn Line
    Displacement6.49 L
    AlternatorBrandStamford
    ModelUCI 274E
    ProtectionIP23
    Frequency fluctuation≤±0.5 %
    Voltage distortion<4%
    Prime Power130KVA(104KW)
    OriginalChina
    Rated voltage400/230 V
    Frequency regulation≤±0.5 %(stable)
    Voltage controlAVR

    Technical parameters of Control Panel:
    BrandDeepseaModel602050 / 60HZ FG WILSON Generator Set , 100KW 125KVA Super Silent Diesel Generator Set
    Function:

    • Start or Stop Generator set manually / automatically

    • High Coolant temperature protection

    • Low Oil pressure protection

    • Over load protection

    • Generator over/under frequency protection

    • Over speed protection

    Note:Indicate this function depend on the set points of the controller in field.

    Optional accessories
    Engine• Heater • Battery Charger
    Alternator• Permanent Magnet Generator(PMG)
    Control system• Remote Control Panel • Auto Transfer Switch (ATS) • Paralleling System
    Fuel system• Daily Fuel Tank • Water Separator • Fuel Level Sensor
    Others• Rainproof Type • Soundproof Type • Trailer Type • Extra spare Parts

    Standard AccessoriesOpen typeSilent type
    Sound-proof & Weather-proof CanopyN/A
    Daily base fuel tank. 8 hours capacityN/A
    Single-bearing generator again drops
    Intelligent LED display control panel
    Speed governor
    Electric start and 12v charger
    Standard air filter, oil filter, fuel filter
    Cooling water tank
    High-efficient silencer.
    Exhaust elbow
    Storage battery
    Steel base-frame against vibration
    Soft pipe for fuel and handle for lube going-out
    Operation& Maintenance manual.

     DrawingDimension
    50 / 60HZ FG WILSON Generator Set , 100KW 125KVA Super Silent Diesel Generator Set

    Open type: 2300*1100*1675 mm


    50 / 60HZ FG WILSON Generator Set , 100KW 125KVA Super Silent Diesel Generator Set

    Silent type: 3265*1163*1858 mm



    Remark:


    Prime Power (PRP): Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97(EQV ISO8528); a 10% overload capability is available for a period of 1 hour within a 12-hour period of operation.


    Standby Power Rating (ESP): The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.


    Warranty:Stone Power provides a full line of brand new and high quality products. Each Genset is strictly factory tested before delivery.


    We offer client warranty of 12 months or 1,000 running hours warranty which comes first (longer warranty period can be offered with extra charge)


    Quick after service and parts are available from Stone Power or distributors in your location.
